Apple M4 Max chip
- 14-core CPU with 10 performance cores and 4 efficiency cores
- 32-core GPU
- Hardware-accelerated ray tracing
- 16-core Neural Engine
- 410GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes and ProRes RAW
- Video decode engine
- Two video encode engines
- Two ProRes encode and decode engines
- AV1 decode
Configurable to:
M4 Max with 16‑core CPU, 40‑core GPU and 16‑core Neural Engine (546GB/s memory bandwidth)
Memory
36GB
36GB unified memory
Configurable to:
48GB, 64GB or 128GB (M4 Max with 16-core CPU and 40‑core GPU)
Storage1
512GB SSD
Configurable to:
1TB, 2TB, 4TB or 8TB
Display Support
M4 Max
Simultaneous support for up to five displays:
- Up to four displays with 6K resolution at 60Hz over Thunderbolt and one display with 4K resolution at 144Hz over HDMI
- Up to two displays with 6K resolution at 60Hz over Thunderbolt and one display with 8K resolution at 60Hz or 4K resolution at up to 240Hz over HDMI
M3 Ultra
Simultaneous support for up to eight displays:
- Eight displays with up to 6K resolution at 60Hz or 4K resolution at up to 144Hz
- Four displays with up to 8K resolution at 60Hz or 4K resolution at up to 240Hz
Thunderbolt 5 digital video output
- Support for native DisplayPort 2.1 output over USB‑C
HDMI display video output
- Support for one display with up to 8K resolution at 60Hz or 4K resolution at 240Hz
- Support for variable refresh rate (VRR), HDR and multichannel audio
Connections and Expansion :
Four Thunderbolt 5 (USB‑C) ports with support for:
- Thunderbolt 5 (up to 120 Gbps)
- USB 4 (up to 120 Gbps)
- USB 3 (up to 10 Gbps)
- DisplayPort 2.1
- Two USB 3 (USB‑A) ports (up to 5 Gbps)
- HDMI 2.1 port
- 10Gb Ethernet
- 3.5 mm headphone jack
On front (M4 Max):
- Two USB‑C ports (up to 10 Gbps)
- SDXC card slot (UHS-II)
On front (M2 Max):
- Two USB-C ports (up to 10 Gbps)
- SDXC card slot (UHS-II)
Communications
Wi-Fi
- Wi-Fi 6E (802.11ax)3
Bluetooth
- Bluetooth 5.3
Ethernet
- 10Gb Ethernet (Nbase-T Ethernet with support for 1Gb, 2.5Gb, 5Gb and 10Gb Ethernet using RJ-45 connector)
Size and Weight
Electrical and Operating Requirements
- Line voltage: 100–240V AC
- Frequency: 50Hz to 60Hz, single phase
- Maximum continuous power: 480W
- Operating temperature: 10° to 35° C (50° to 95° F)
- Storage temperature: –40° to 47° C (–40° to 116° F)
- Relative humidity: 5% to 95% non-condensing
- Operating altitude: tested up to 5,000 m (16,400 ft)
In the Box
- Mac Studio
- Power cord3
Operating System : macOS
