Mac Mini: Apple M4 Pro chip with 8‑core CPU and 10‑Core GPU
Chip : Apple M4 Pro chip
- 12-core CPU with 8 performance cores and 4 efficiency cores
- 16-core GPU
- Hardware-accelerated ray tracing
- 16-core Neural Engine
- 273GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Configurable to:
- M4 Pro with 14‑core CPU and 20‑core GPU
- 24GB unified memory
Configurable to:
- 48GB or 64GB
- 512GB SSD
Configurable to:
- 1TB, 2TB, 4TB, or 8TB
M4 Pro
Simultaneously supports up to three displays:
- Up to three displays: Three displays with up to 6K resolution at 60Hz over Thunderbolt or HDMI
- Up to two displays: One display with up to 6K resolution at 60Hz over Thunderbolt and one display with up to 8K resolution at 60Hz or 4K resolution at 240Hz over Thunderbolt or HDMI
Thunderbolt 5 digital video output
- Support for native DisplayPort 2.1 output over USB‑C
HDMI display video output
- Support for one display with up to 8K resolution at 60Hz or 4K resolution at 240Hz (M4 and M4 Pro)
- Supported formats include HEVC, H.264, AV1 and ProRes
- HDR with Dolby Vision, HDR10+/HDR10 and HLG
- Supported formats include AAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus and Dolby Atmos
- Built-in speaker
- 3.5 mm headphone jack with advanced support for high-impedance headphones
- HDMI port supports multichannel audio output
On front:
- Two USB-C ports with support for USB 3 (up to 10 Gbps)
- 3.5 mm headphone jack
On back (M4 Pro):
- Gigabit Ethernet port (configurable to 10Gb Ethernet)
- HDMI port
Three Thunderbolt 5 (USB-C) ports with support for:
- Thunderbolt 5 (up to 120 Gbps)
- USB 4 (up to 40 Gbps)
- DisplayPort
Wi-Fi
- Wi-Fi 6E (802.11ax)
Bluetooth
- Bluetooth 5.3
Ethernet
- 10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)
- Configurable to 10Gb Ethernet (Nbase-T Ethernet with support for 1Gb, 2.5Gb, 5Gb and 10Gb Ethernet using RJ-45 connector)
Height: 4.97 cm (1.96″)
Width: 12.70 cm (5.00″)
Depth: 12.70 cm (5.00″)
Weight (M4): 0.67 kg (1.48 lb.)
Weight (M4 Pro): 0.73 kg (1.61 lb.)
Line voltage: 100–240V AC
Frequency: 50Hz to 60Hz, single phase
Maximum continuous power: 155W
Operating temperature: 10° to 35° C (50° to 95° F)
Storage temperature: –40° to 47° C (–40° to 116° F)
Relative humidity: 5% to 90% non-condensing
Operating altitude: tested up to 5,000 m (16,400 ft)
Typical acoustical performance: Sound pressure level (operator position): 5 dBA at idle
- Mac mini
- Power cord
